AW38 17" touch screen wall-through ATM with cash dispenser, ticket printer and industrial computer

Overview

Quick Details

Place of Origin:

China (Mainland)

Brand Name:

ZKTEK

Model Number:

AW38

Applications:

bank ATM, payment ATM, card vending, bill payment, top up recharge

Custom Options:

Color, configurations, logo, pictographics and any

Main Features:

Outdoor, waterproof, UL291 Lv1, CEN L safe compliant,

Other Features:

Cost-effective full-function ATM

Configurations:

Touchscreen, cash/coin mechanism,industrial IPC etc

Net Weight:

310Kg

Gross Weight:

350Kg

Machine Dimensions:

H:1753mm x W:560mm x D:1080mm

Package Dimensions:

H:1753mm x W:560mm x D:1080mm

Working Conditions:

0-50 D. Celsius, 5-95% NC, 100-240V AC 6A

Basic Info.

• Brand Name:ZKTEK
• Product Model:AW38
• Product Size: 1753mm x 560mm x 1080mm (WxDxH)
• Product Color: (custom)
• Product NetWeight: 310 KG
• Product GrossWeight: 350 KG
• Product Operation Temperature: 0°C-50°C(below 0°C must use heater)
• Product Storage Temperature: -20°C-55°C(below 0°C must use heater)
• Product Certificates: CCC, compliant with UL291 Level 1
• Product Availability: 2017.9
• Installation method: Wall-through
• Model No.: KY8651
• Min.Order: 5 Set/Sets
• Means of Transport: Air

Supply Capacity

• Production Capacity: 600 sets per month
• Packing:Carton, Plywood box
• Delivery Date: 60 days.

Detailed

AW38 series ATM is a high performance andreliable ATM product provided by ZKTEK for the deployment of off-premise ATM, selfservice banks, savings banks, largemalls, stared hotels, large factories and mines, high schools and largeamusement parks etc.

This series contains two models: AW38E standalone selfservice ATM, and AW38X wall-through ATM with internal display. Both of these models areutilising the unique design of auti-vandalism, water-proof anddust-proof mechanism to leverage the durability and security of ATMproducts for 7/24 operation standards.

The module of the ATM is provided by Glory(Delarue), Fujitsu or NCR depending on the requirement of the users.

Standards of the products: "General regulation of ATM: GB/T18789-2002"; compliant to UL291 level 1 and CEN L provide the drivers forWOSA/XFS CEN.

Applications

ü         Bank cash withdraw

ü         School tuition and scholarship cash withdraw

ü         Theme park cash withdraw

ü         Casino counter/coin redemption

ü         Airport exchange giving

ü         Mines and factories Salary dispensing

ü         Car Wash changes giving

ü         Off-premise ATM for un-attended banks

Features

ü          Cost-effective full-function ATM

ü          Reliable large volume cash dispensing module

ü          With front and rear accessible safe

ü          UL291 Level 1 /CEN L compliant

ü          Drivers for WOSA/XFS CEN

ü          Slim enclosure, very easy to use in various applications

ü          Anti-skimming card reader

ü          Short leadtime:  available for sample in 30 days to shipment

1.1      technical introduction

(1)          Complete function and diversified withdraw method

Accept the transaction request using ISO standard magnetic card orbankbook(optional) to withdraw, transfer,inquiry, change password andother intermedia business which defined by the host computer of thebank.

(2)          Exquisite appearance, variable configurations and easy installation

The dimensions of this machine is slim, modern style and sturdy. It issuitable for deployment for off-premise selfserfice banks, savingsbanks, large malls, star hotels, large factories and mines, schools anduniversities etc.

(3)          Quality guarranty, low-price, and high effecient

The core module: cash dispenser is provided by Glory, FUJITSU or NCR. It's ahighspeed, high reliability module which is the most popular in seriousATM projects. The large dispensing amount in single transaction providesthe ability to dispense 60 notes in one transaction to make sure thelarge amount withdraw more comfortable.

Main functions

Business functionality

(1)          Bank transaction service

Include withdraw, change password, balance inquiry, detail inquiry, transfer and intermedia operation.

(2)          Cash handling function

The cash dispensing module has the electronical shutter, automaticretract function; utilising the stacked cash dispensing function, withcash escrow and defected notes box. Standard configurations has 1cassettes, and scalable to 3 cassettes( if without internal UPS, thecassettes can be extended to 4 total). 3000 notes per cassette.

Management function

(1)          Support bank management service

Including active manage service and passive manage service. Forexample: CASH REPLENISHMENT, CLEAR CASSETTES, ACCOUNT BALANCING POSTING,PARAMETER DOWNLOAD, KEY MANAGEMENT etc; REMOTE LOGIC POWER-ON, REMOTELOGIC POWER-OFF, STATUS INQUIRY etc.

(2)          Support all kinds of credit and debit cards

The cardreader is the motorised hybrid reader, and it can readHI-CO/LO-CO magnetic card, IC card, and PAYPASS contactless card.

(3)          Support electronic and printed journal

Provide electronicdaily journal and printed daily journal functions

(4)          Providing receipt printing and presenting function

Security Function

(1)          Providing software and hardware encryption function

(2)          Providing anti-peak function

(3)          Providing 4 channel video recording camera(3 internal and 1 external)

(4)          Providing embedded digital video surveillance system

(5)          Providing digital HDD video recorder(optional)

(6)          Providing vibration alarm and body/face mask sensor alarm(optional)

Other function

(1)          Providing UPS power(default)

(2)          Providing heater module(optional)

(3)          Supporting WOSA CEN/XFS protocol SP drivers

(4)          Certificated by CCC and Police security standards.
