B743 kiosk box IPC with DVD-ROM

Model: B743

  • The dual lan network is used for the redundant connection.
  • The computer has 8x USB ports.
  • USB 3.0 has two pairs of differential signals in addition to USB 2.0 signals
  • The computer has 6xCOM which are available for more connections.
  • The box IPC has the DVD which can be used for install the OS and drivers.
  • 1U is a slim formfactor for the compact rackmounted IPC.
  • mini is business:more and more items are looking at mini solution
B743 kiosk box IPC with DVD-ROM
B743 kiosk box IPC with DVD-ROM

B743 i5/i7/XEON CPU kiosk box IPC with DVD-ROM

MAIN FEATURES

  • DualLAN

    The dual lan network is used for the redundant connection.

  • 8xUSB

    The computer has 8x USB ports.

  • USB3.0

    USB 3.0 has two pairs of differential signals in addition to USB 2.0 signals

  • 6xCOM

    The computer has 6xCOM which are available for more connections.

  • DVD

    The box IPC has the DVD which can be used for install the OS and drivers.

  • 1U

    1U is a slim formfactor for the compact rackmounted IPC.

  • mini

    mini is business:more and more items are looking at mini solution

  • B743 i5/i7/XEON CPU kiosk box IPC with DVD-ROM




  • Configurations

    • Box IPC: B74X Specifications

      Item Parameter
      CPU Intel i3 4160T CPU/Haswell LGA1150/3.1GHz/3M Cache/22nm/TDP:35W
      Chipset Intel H81 chipset
      Video ability Support VGA, DVI, HDMI
      - Support VGA+DVI,VGA+HDMI, DVI+HDMI asynchronous dual independent display
      Video core Intel HD Graphics 4400 graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 32GB)
      Power supply DC 12V voltage, recommend current: 5A
      Storage 2* Serial ATA II, support 3Gb/s
      - 16G SSD/500G HDD(legacy 2.5″ hard driver)
      Ethernet Onboard 1*RTL 8111E 100~1000 BaseT LAN,support RTL and PXE
      - 2*MINI-PCIE support MSATA, WIFI, GPS and 3G
      Audio Realtek ALC662 Codec providing 6 channel output
      LVDS LVDS 24bit LVDS, support 1920*1080 full HD
      Audio Onboard
      USB 6*USB 2.0, plus 2*USB 3.0
      Backplane interface 1*DC 12V
      - 1*HDMI,1*VGA,1*DVI
      - 2*COM
      - 1*RJ-45 1000M
      - 4*USB 2.0+2*USB 3.0+2*USB2.0 on face panel
      - 1*Audio out
      - 1*MIC
      Built-IN interface 2*USB pin head,support for 4 x USB
      - 1*DC power supply output interface
      - 2*COM1/2-9 pin head
      - 1*M-COM pin head,support for 4 x COM
      - 1*Amplified Speaker-OUT(1-3W)
      - 1*FAN power supply pin head
      - 2*MINI-PCIE
      BIOS AMI 16M BIOS, ACPI supported,support resume on power fail, power-on timer
      Environment Operation temperature: 0~+55 degrees Celsius
      - Storage temperature:-20~+80 degrees Celsius
      RH 10%~90%(non-condensing)
      Motherboard size MITX(170mm*170mm)
      Box IPC size 234mm*180mm*100mm
      Net weight 3.3KG
      Gross weight 4.7KG
      Color Black(customizable for several color as red, yellow, grew, black, white and green etc)
      Housing material Duralumium(high density aluminum)
      Paint material Sandblasted Aluminum Oxidation
      OS Windows XP, 7, Android 4.2 and above,
      - Linux 2.6 and above, the other OS with Linux Core(i.e. Ubuntu 12.4, 14.4)
      Warranty TWO years
