ZKTEK provides all kinds of custom OEM/ODM ATM machine,interactive kiosk,information kiosk, touchscreen kiosk, touchscreen monitor, touchscreen computer, box ipc,digital sginages, pos and metal keyboard products

G87 desktop touchscreen kiosk with barcode reader and thermal printer

Model: G87

  • Linux Ready
  • Web based internet access is used for the applications developped based on web browse and websites.
  • Handicapped kiosk are specially designed for the handicapped person.
  • Multitouch is the touchscreen with the multi touch points simultaneously.
  • Projective capacitive touch or projective-capacitance touch screen is the technology that use the reflective technology to install the capacitive sensors on the rear side of the touchscreen, and makes the touchscreen absolutely isolated from the environment interference.
G87 desktop touchscreen kiosk with barcode reader and thermal printer
G87 desktop touchscreen kiosk with barcode reader and thermal printer

G87 is a desktop touchscreen kiosk with barcode reader and thermal printer

MAIN FEATURES

  • Linux Ready

    Linux is a set of free Unix operating system, which is based on and similar to POSIX and UNIX.

  • Internet

    Web based internet access is used for the applications developped based on web browse and websites.

  • Handicapped

    Handicapped kiosk are specially designed for the handicapped person.

  • Multitouch

    Multitouch is the touchscreen with the multi touch points recognition simultaneously.

  • Projective capacitive touch

    Projective capacitive touch, also as projective-capacitance touch screen is the technology that use the reflective technology to install the capacitive sensors on the rear side.

  • G87 is a desktop touchscreen kiosk with barcode reader and thermal printer.

    OEM/ODM is welcome.




  • Configurations

    • Barcode kiosk with J1900 Specifications

      Name Model Item Parameter
      Host PC ZKTEK TN-J1900 CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      Touchscreen ZKTEK C1710C Type 17 inch capacitive touchscreen
      Durability Scratch-free,More than 35,000,000 touches in one location without failure
      - antirust, anti-acid, anti-dust
      Thickness 6mm
      Resolution 4096x1096
      Light Transmission 90%-92%
      Surface Hardness Mohs
      Touch force <100g
      Response Time 16ms
      Interface USB
      Thermal Printer CUSTOM K80 Printer Type Direct Themal Printer
      Paper width 80mm
      Paper roll diameter 180mm
      Paper thickness 60 to 120g/m2
      Print Speed 130mm/s
      Print resolution 203 dpi (8 dots/mm)
      Sensors Automatic cutter only;out alarm/to be run out alarm,Jam
      Power supply 24VDC2.5A
      Interface RS232 / USB / Ethernet
      Barcode Scanner HONEYWELL N5680 Decoding capability Read almost all formats of 1D and 2D barcode
      Scan width(degree) +/-40 degree Scan angle: 360 degree Movement tolarence
      Minimium size 6.60 mil (PDF 417)
      Interface RS232/USB
      Power supply 5V or over USB
      Brand HONEYWELL
      Movement tolarence 4 inch/second
      Audio ZKTEK AUDIO5W AUDIO Stereo amplified speakers: dual channel 5W8Ohm
      Enclosure ZKTEK G Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
