F1 slim and sleek self service free standing standalone touchscreen kiosk with receipt printer or A4 laser printer

Model: F1

  • WIFI
  • Web based internet access is used for the applications developped based on web browse and websites.
  • Thermal printer is used to provide high speed receipt and other transaction-related slips.
  • Rugged kiosk is used for the applications which needs high quality kiosks.
F1 slim and sleek self service free standing standalone touchscreen kiosk with receipt printer or A4 laser printer
F1 slim and sleek self service free standing standalone touchscreen kiosk with receipt printer or A4 laser printer

F1 is a slim and sleek self service free standing standalone touchscreen kiosk with receipt printer or A4 laser printer

MAIN FEATURES

  • WIFI

    WiFi is a networking technology that allows devices to communicate without wires.

  • Internet

    Web based internet access is used for the applications developped based on web browse and websites.

  • Thermal printer

    Thermal printer is used to provide high speed receipt and other transaction-related slips.

  • Rugged kiosk

    Rugged kiosk is used for the applications which needs high quality kiosks.

  • The F1 is a free standing standalone touchscreen kiosk. With the additional card reader, metal EPP and thermal printer etc, F1 is capable to handle the cash payment and card payment as well as the barcode authentication for the payment industry and various of billing applications. Other options, such as the RFID(NFC) reader is also available with this model: F1 is ideal for the application needing a lot of features in small foot print.

    By adopting the most up-to-date technology and powerful high performance industrial computer for 24/7 use, The slim touch screen kiosk is design to cater the increasing demand of the multifunctaional kiosks. The business owners will benefit from the multifunction ways to quickly and conveniently manage their business with the kiosks in every day operation in compact and sturdy design at a reasonable cost.

    Now, F1 features the most latest technologies:

    •  The complete clean and smooth front interface with projective capacitive touchscreen monitors(optional)
    •  The state of art design and good finishing of outlook surface
    •  High reliable industrial computer with the latest HASWELL server technology
    •  Embedded high-speed high-reliability cash acceptor(optional)
    •  Hybrid motorised 3-in-1 bank card reader(optional)
    •  Durable high speed thermal printer(optional)
    •  Optional SIM socket for cellular radio 4G/LTE connectivity(optional)
    •  Optional bulky components such as bank pass book printer, change giver and A4 laser printer for list printing

    F1 is the accoutable solution for the high foot traffic and high quality service companies as a decent multi functional free standing kiosk in 24/7 work-time. With ZKTEK, you will have the tools and support you need for a successful self service automated multi functional free standing kiosk.

    OEM/ODM/BRANDING are also welcome.


    Applications:

    • Billing Kiosk
    • Marketing Kiosk
    • Music Download Kiosk
    • Multimedia Kiosk
    • On-Line Banking Kiosk
    • Order Entry Kiosk
    • Bespoken Kiosk



    • Prepaid Kiosk
    • Redemption Kiosk
    • Retail Kiosk
    • Security Kiosk
    • Self-Service Kiosk
    • Ticketing Kiosk
    • Tourism Kiosk



    • Trade Show Kiosk
    • Payment Kiosk
    • Check In Kiosk
    • Custom Kiosks
    • Directory Wayfinder Kiosk
    • Employee Self-Service Kiosk
    • Gaming Kiosk



    • Gift Registry Kiosk
    • HR Kiosk
    • Identification Verification Kiosk
    • Information Kiosk
    • Interactive Kiosk
    • Internet Kiosk
    • Internet Pay For Use Kiosk



    • Kiosk OEM
    • Kiosk ODM



  • Configurations

    • hospital kiosk with laser printer and metal keyboard Specifications

      Name Model Item Parameter
      Host PC ZKTEK TN-X1265LV3 CPU Intel XEON E3-1265L V3.0 , quad core 3.7GHz, 5GT/s FSB
      Video core Integrated Intel?HD Graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5" hard driver)
      Touchscreen Monitor ZKTEK C191 Touch technology 19 inch projective capacitive touch
      Multi-touch points 1
      LCD display Resolution 1280x1024(LCD)
      Touch screen Resolution 4096x4096
      Durability Scratch-free,More than 35,000,000 touches in one location without failure
      Thickness 6mm;
      Protection Vandalism proof, antirust, anti-acid, anti-dust
      Surface Hardness Mohs
      Touch force <100g; Response Time:16ms; Agency Approval:CE, FCC
      Impact protection Withstand the impact of a 500g steel ball, dropped from a height of 1.3 meters
      Interface: USB
      Power supply (over USB)
      MTBF >50000 hrs
      Light Transmission 90%~92%
      Metal Keyboard ZKTEK MKT2752 Type 64Keys stainless steel metal leyboard with trackball(IP65 NEMA 4X);
      Faceplate: 372*102mm
      Trackball Diameter 38mm
      Lettering Sunk laser legends & characters in high quality ink
      Switch life more than 2 million of operations
      Standards Compatible with CE, RoHS, FCC
      Layout Internet -English(EN04), customizable for all languages
      Interface USB
      Enclosure ZKTEK F Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
      Laser Printer SAMSUNG ML2160 Printer Type Black/white Laser printer
      Language All kinds of character set optional
      Speed 20ppm
      First Print Out <8.5s
      Size A4
      Max resolution 1200 x 1200dpi
      Capability 10000 pages per month
      1st tray storage 150 sheets
      Memory 8MB
      Dimensions 331 x 215 x 178mm
      Netweight 4.0kg
      Power supply 220V-240V AC
      Interface USB 2.0
      Camera ZKTEK PHC1 Camera Type CMOS
      Resolution 2MP active pixels
      Functions Auto-focus
      Interface USB2.0 High Speed(EHCI)
      Audio ZKTEK AUDIO5W AUDIO Stereo amplified speakers: dual channel 5W8Ohm
      Package ZKTEK Crate Material Plywood crate
      Wrapper Film
      Foam (only corners)
